High-Performance Thermal Management, Forged for Excellence
combine advanced forging technology with premium-grade aluminum to deliver superior thermal conductivity, mechanical strength, and durability
🔷Features
- High Thermal Conductivity – Efficiently transfers heat away from components.
- Forged Strength – Exceptional structural integrity and resistance to deformation.
- Lightweight Design – Reduces overall system weight without sacrificing performance.
- Precision Finish – Smooth surfaces for optimal contact with heat sources.
- Customizable – Available in various sizes, shapes, and anodized finishes.
🔷Specifications
- Material: AL1070
- Width: 125mm
- Length: 125mm
- Total Height: 70mm
- Weight: 0.95kgs per piece
- Secondary Process: CNC machined, drilling holes, tapping, etc
- Surface Treatment: color anodized, hard anodized, matte, sand blasting, polishing, etc.
- Thermal Resistance: 0.58℃/W
- Using Power: 80-100Watts
🔷Applications
- Power Electronics & Inverters
- LED Lighting Systems
- Electric Vehicles (EVs) & Battery Packs
- Industrial Automation Equipment
- Renewable Energy Systems
🔷Why Choose Our Forged Heatsinks?
Forging refines the metal’s grain structure, enhancing both strength and thermal performance compared to extruded or cast alternatives. This ensures your devices operate cooler, last longer, and perform at their peak.
🔷Contact Us
- Upgrade your thermal management with Aluminum Forged Heatsinks built for demanding environments.
- Contact us now to discuss your custom design needs.
